FANRYN External Wall Insulation Rock Wool Blanket - A1 Fire Rated for Building Facades

Informations de base
Lieu d'origine: CHINE
Nom de marque: FANRYN
Détails d'emballage: Sac en plastique
Délai de livraison: 15 jours de travail
Conditions de paiement: T / t
Détail Infomation
Résistance à la compression: 20 psi Incendie: Classe A
Indice de propagation de la flamme: 25 Conductivité thermique: 0,23 w / m · k
Résistance à la traction: 50 psi Résistance chimique: Résistant à la plupart des produits chimiques
Plage de température: -40 ° F à 1200 ° F Perméabilité à la vapeur: 0,05 permanentes
Épaisseur: 1 pouce Matériel: Laine minérale
Absorption: NRC 0,85 Résistance à l'humidité: Non hygroscopique
Indice développé par la fumée: 50 Densité: 2,5 lbs / pi³
Mettre en évidence:

A1 fire rated rock wool blanket

,

external wall insulation mineral wool

,

building facade rock wool blanket


Description de produit

Product introduction of the Rock Wool Blanket

FANRYN Rock Wool Blankets are engineered for insulating large-diameter industrial pipelines in power plants, refineries, and chemical processing facilities. With a melting point exceeding 1000°C and low thermal conductivity (≤0.044 W/mK), our blankets provide superior thermal insulation and fire protection for high-temperature applications. The uniform fiber structure ensures consistent performance, reducing energy loss and protecting personnel.

Production details of the Rock Wool Blanket

FANRYN External Wall Insulation Rock Wool Blanket - A1 Fire Rated for Building Facades 0

FANRYN External Wall Insulation Rock Wool Blanket - A1 Fire Rated for Building Facades 1

Product parameter of the Rock Wool Blanket

Properties

Blanket

Standards

Density Tolerance

±10%

GB/T 19686-2005

Fire Performance

Non-Combustible

GB/T 5464-1999

Reaction to fire Class A1

GB/T 8624-2006

Thermal Conductivity
(W/mK, at70±5℃)

≤0.044

GB/T 10295

Fiber Diameter

7(+/-1)um

GB/T 5480. 4

Shot Content
(shot size>0.25mm)

≤12%

Moisture Content

≤0.5%

Organic Matter Content

≤4%

Melting Point

>1000℃

Product size of the Rock Wool Blanket

Product

Blanket

Density (kg/m3)

60-100

Size: L x W (mm)

600X5000

Thickness (mm)

30-150

Product feature of the Rock Wool Blanket

  • Thermal Insulation
  • Fire Safety
  • Acoustic Control
  • No Corrosion
  • Environmental friendly
  • Moisture Resistance
  • Energy Conservation & Emissions Reduction

Product application of the Rock Wool Blanket

  • Insulation for external wall, roofing and floating floor
  • Insulation for big sized pipeline
  • Rock wool blanket is widely used in public, commercial and residential buildings as well as industrial plants, for applications such as roofing, external wall, partition wall and floating floor to provide fire protection, thermal insulation, acoustic control and condensation control.

FAQ:

Q1: How to guarantee the quality of the products?

A1: Our experienced QC team will inspect product's quality in every process

Q2: How to pack exported goods?

A2: Plastic bag + woven bag (Standard Export Packing).

Q3: what is your lead time for one 40HC container order?

A3: Usual 15-20 work days after placing order

Q4: What is your advantage on Rock Wool Blanket?

A4: Special product with special specification can be made to order.

Q5: About the after-sale service, how to solve the problems occurred of your overseas customer in time?

A5: The warranty of our products is one year. If our products or packing exist quality problem, we will replace or compensate accordingly.
